| Place of Origin: | Germany |
|---|---|
| Brand Name: | Beckhoff |
| Model Number: | KL3314 |
| Minimum Order Quantity: | 5 pcs |
| Packaging Details: | standard export package |
| Delivery Time: | 5-8 working days |
| Payment Terms: | T/T |
| Model | KL3314 |
| Input Points: | 4 |
| Power Supply: | powered by K-bus |
| Thermocouple Sensor Type: | J, K, L, B, E, N, R, S, T, U type (default setting: K type), mV signal measurement |
| Connection Method: | 2-wire system |
| Temperature Range: | depends on the measuring range of each sensor (default setting: K type: -100… + 1,370 ° C) |
| Resolution: | 0.1°C / digital |
| Conversion Time: | ~ 250 ms |
| Wiring Fault Indication: | yes |
| Measurement Error: | <± 0.5% (full scale) |
| Electrical Isolation: | 500 Vrms (K-bus / signal voltage) |
| K-bus Current Consumption: | 75mA |
| Bit Width in Process Image: | input: 4 x 16 bit data (4 x 8 bit control / status optional) |
| Configuration: | no address setting, configuration via bus coupler or controller |
| Weight: | 75g |
| Working / Storage Temperature: | 0…+55 °C/-25…+85 °C |
| Relative Humidity: | 95%, non-condensing |
| Anti-vibration/ Impact Resistance: | comply with EN60068-2-6/ EN60068-2-27/29 |
Other model KL3312/KL2124/EL1002/KL3351 can also be provided according to customers' requirements.
